Case Study

Opportunities in floating offshore wind platforms

Uncovered top offshore platform designs through deep patent analysis and expert-driven opportunity mapping

CamIn works with early adopters to identify new opportunities enabled by emerging technology.

Revenue:
$10 billion+
Employee headcount:
50,000+
Opportunity:
Energy transition
Sponsored:
Head of innovation
%

of CamIn’s project team comprised of leading industry and technology experts

CamIn’s expert team

Our infrastructure client wanted to analyse new floating offshore platform designs to productise this service and capture the growing market. CamIn identified 5 winning concepts to de-risk client’s investment into product development

Industry:
Infrastructure and engineering
Revenue:
$10 billion+
Employee headcount:
50,000+
Opportunity:
Energy transition
Sponsored by:
Head of innovation
$
45,000

For $45,000 we have enabled the client to secure pilots with key pioneers before the competition
3
expert teams

3 external expert teams specialised in floating offshore platform design, early-stage technologies, and construction
5
x faster

CamIn completed the work in 6 weeks, 5 times faster than the client’s internal team
Discover more opportunities in
Energy transition
Contact Us
Our infrastructure client wanted to analyse new floating offshore platform designs to productise this service and capture the growing market. CamIn identified 5 winning concepts to de-risk client’s investment into product development

Client's problem

The client was building floating offshore platforms for its customers, but decided to productise this service as part of the diversification strategy. That meant they needed to create a unique competitive design, based on the lessons learned from their competitors who pioneered this technology space. They lacked the internal expertise to analyse the multitude of designs, materials, and geography-specific requirements. The client also did not have access to expertise to analyse the outcomes of the past pilots to extract learning points.

CamIn's solution

Key questions answered

  1. What are the functions, KPIs, strengths, and weaknesses of each floating offshore technology, and how will they evolve?
  2. Who are the key academic, startup, and corporate players and what patents and pilot projects are they involved in?
  3. What is the expected commercialisation timeline for each technology?
  4. What are the lessons learned and what design elements are becoming superior?

Our Approach

261

Expert teams went through 1000+ of patent families to filter out irrelevant ones and select the most relevant 261 patent families for further analysis.

250

We analysed 250 patent families based on credibility of the patents, presence of the concept in the public domain, and awareness about the concept in the expert circles.

61

Then we assessed the selected 61 concepts based on 10 KPIs collected from the patents, public domain, and expert knowledge.

5

Finally, we segmented the concepts into "highest", "high", "medium", and "low" opportunities. The 5 winning concepts were analysed to extract the best-practices to create a preliminary blueprint.

Results and Impact

Analysed over 250 patent families and 60 floating offshore wind platform designs to identify key features, materials and their impact on platform suitability to specific applications.

Identified design features suitable for client's target geography and 5 pilot partners who have been pioneering these.

Provided a blueprint outline how a potential product could look like given the best-practices.

Example Outputs

What are floating offshore wind platforms?

Floating offshore wind platforms (FOWPs) are large-scale engineered substructures, typically made of steel, concrete, or hybrids, that support wind turbines in deep water where traditional fixed-bottom foundations are not feasible. These platforms are stabilised by combinations of ballast, mooring systems, and water-plane area, allowing them to operate efficiently even in challenging oceanic environments. They come in various classes such as spar-buoy, barge, semi-submersible, and tension leg platforms, each suited to different depths, seabed conditions, and logistical constraints.

Spar-Buoy

Stability Principle: Ballast-stabilised (heavy mass low in the structure).

Key Characteristics:

  • Deep draft; requires >100m water depth.
  • Simple, slender vertical structure.
  • Very stable in harsh sea conditions.
  • Lower wave-induced motion.
  • Requires heavy-lift vessels and deepwater ports.
  • Not easily towable once installed, so is difficult to maintain.

Barge

Stability Principle: Water-plane stabilised (large surface contact with water).

Key Characteristics:

  • Shallow draft suitable for shallower waters and quayside assembly.
  • Wide, flat structure that resists roll and pitch.
  • Easy to manufacture and tow.
  • Susceptible to wave-induced motion.
  • Good for early-stage or smaller turbine installations.
  • Scalability to larger turbines remains a challenge.

Tension Leg Platform (TLP)

Stability Principle: Mooring-stabilised (taut vertical tendons).

Key Characteristics:

  • High stability once anchored with minimal platform motion.
  • Small seabed footprint.
  • Uses excess buoyancy pre-installation for tow-out.
  • Complex and costly mooring systems.
  • Low draft that enables shallow water assembly.
  • Currently less mature commercially.

Semi-Submersible

Stability Principle: Water-plane + buoyancy stabilisation.

Key Characteristics:

  • Multiple columns connected by pontoons.
  • Moderate draft, suitable for quayside integration and tow-out.
  • Supports large turbines (up to 15MW+).
  • High flexibility in global deployment.
  • Complex structure and high material cost.
  • Easier O&M: can be towed back to port for major work.

Why are floating wind platforms important?

Floating offshore wind platforms (FOWPs) are emerging as a critical technology in the transition to net zero. By enabling wind energy generation in deeper waters, they expand the geographic and technical potential of offshore wind and play a key role in both decarbonisation and energy security strategies worldwide.

  • Unlock high-quality wind resources: FOWPs access stronger, more consistent wind speeds located farther offshore, boosting energy yields and capacity factors.
  • Bypass land and nearshore constraints: Unlike onshore or fixed-bottom wind, floating platforms avoid land-use conflicts, reduce visual and environmental impacts, and face fewer permitting challenges.
  • Enable wind deployment in deep waters: FOWPs open new markets in regions with deep continental shelves, such as the US West Coast, Japan, and Southern Europe, where traditional offshore wind is not feasible.
  • Support national-scale energy strategies: Floating wind expands the scope for large-scale renewable energy projects, helping nations diversify their energy mix and meet climate targets.
  • Enhance energy security and resilience: By tapping domestic wind resources in previously inaccessible areas, FOWPs reduce reliance on imported fuels and increase the stability of power systems.

What opportunities do floating wind platforms enable?

Floating offshore wind platforms are set to reshape the global clean energy landscape by enabling high-capacity deployment in deeper waters. Over the next decade, they will catalyse new market creation, infrastructure innovation, and cross-sector collaboration, positioning floating wind as a cornerstone of the energy transition.

  • Accelerated global deployment: Floating wind is projected to reach over 30 GW of installed capacity by 2035, up from under 1 GW today, unlocking new energy markets across Asia, North America, and Southern Europe.
  • New value chains and investment streams: The growth of floating wind will drive demand for specialised fabrication facilities, turbine integration ports, dynamic cabling, and offshore logistics, generating opportunities for OEMs, shipbuilders, EPCs, and utilities.
  • Modular and cost-efficient maintenance models: Designs such as semi-submersibles and tension-leg platforms allow for tow-to-port servicing, reducing downtime and lowering total lifecycle costs compared to fixed-bottom alternatives.
  • Emerging hybrid applications: Floating wind is enabling the development of integrated energy hubs, such as wind-to-hydrogen platforms and offshore charging stations for vessels, expanding the role of wind in broader energy systems.
  • Boost to local industrial ecosystems: National and regional strategies supporting floating wind will stimulate job creation, skills development, and innovation across construction, engineering, and digital sectors, particularly in areas with underutilised port infrastructure.

What technologies are emerging for floating offshore wind platforms?

The next decade will be pivotal for the industrialisation of floating offshore wind platforms. A suite of enabling technologies is maturing in parallel to make deployment faster, more scalable, and commercially competitive with fixed-bottom alternatives.

  • Next-generation mooring and anchoring systems: Advanced dynamic mooring solutions, including synthetic ropes and taut-leg configurations, will enable secure deployment in deeper waters while reducing footprint and seabed impact.
  • Digital design and simulation tools: Widespread use of digital twins, CFD modelling, and AI-driven optimisation will allow developers to simulate platform performance under varied sea states, reducing prototyping costs and accelerating certification.
  • Modular and automated fabrication methods: Standardised substructure designs and modular construction using shipyard infrastructure will reduce capital costs and unlock economies of scale. Automated welding, pre-fabrication, and robotic assembly are key to accelerating build-out.
  • Advanced materials and structural innovation: The use of lightweight composites, corrosion-resistant coatings, and high-strength steel alloys will improve structural performance while reducing load requirements and transportation costs.
  • Autonomous operation and maintenance systems: Robotics, drones, and unmanned surface vessels (USVs) will be deployed for tasks such as subsea inspection, blade cleaning, and anchoring assessments, increasing safety and lowering operating expenses.
  • Hybrid platform designs: New concepts like HexaFloat and TetraSpar will mature, blending different stability mechanisms to increase geographic adaptability and reduce installation complexity.
